10" Industrial-Grade Plastic Hand Cup for Curved Surfaces
Stock: 91760
Model: N6000
This lightweight, heavy-duty hand cup easily attaches to curved nonporous surfaces, to support loads weighing up to 175 lbs (79 kg).
Details
Note: Not for use on thin, fragile materials such as
flat, regular glass less than 1/4" (6.35 mm) thick.
- Effective attachment to curved loads (not recommended for flat loads)
- Red-line indicator warns user of any significant vacuum loss
- Supplied with protective carrying case
Specifications
Instructions Download
Troubleshooting Download
Load Capacity 175 lbs (79 kg)
Surface Texture Smooth
Material Porosity Nonporous
Allowable Surface Curvature Curved
Material and Ambient Temperature Range 10° F (-12° C) — 120° F (49° C)
Ideal Uses Curved or irregular nonporous surfaces
Pad Diameter 10" (25 cm)
Pad Model G0750
Rubber Type Standard
Handle Type Industrial-Grade Plastic
