- 10" Hybrid Hand Cup for Curved Surfaces
Product(s) sold through Authorized Dealers
10" Hybrid Hand Cup for Curved Surfaces
Stock: 91640
Model: N6300
This hand cup features a metal handle with an industrial-grade plastic plunger that's economical to replace. It attaches easily to curved, nonporous surfaces, to support loads weighing up to 175 lbs (79 kg).
Details
Note: Not for use on thin, fragile materials such as
flat, regular glass less than 1/4" (6.35 mm) thick.
- Effective attachment to curved loads (not recommended for flat loads)
- Red-line indicator warns user of any significant vacuum loss
- Supplied with protective carrying case
Specifications
Instructions Download
Troubleshooting Download
Specifications Download
Load Capacity 175 lbs (79 kg)
Surface Texture Smooth
Material Porosity Nonporous
Allowable Surface Curvature Curved
Material and Ambient Temperature Range 10° F (-12° C) — 120° F (49° C)
Pad Diameter 10" (25 cm)
Pad Model G0750
Rubber Type Standard
Handle Type Metal
WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
(Click here for Dealer information.)
You may also be interested in the following product(s)
Associated Parts
Stock#: 49586T
Model#: G0750
Model#: G0750
